1.We value every inquiry sent to us, ensure quick competitive offer.
2.Suitable package to ensure goods safety and save container space
3.Fast and on-time delivery
4.Two year warranty, lifetime maintenance.
5.Powerful OEM/ODM capacity
6.More than 10 years' manufacturing experience
7.Professional Sales & After Sales Team, provide customers professional and efficient services.
8.QC/QA team makes sure all products with strict quality control.
Syp2900c functions are as follows:
1. 1. Setting function: 1. Setting flow rate value.
2. Set the infusion flow value.
3. Set the infusion rate.
2. When the infusion pump stops running, the setting parameters can be modified online.
3. Display mode: high brightness digital display
4. When the infusion pump works, pressing any key will not affect the normal operation of the infusion pump, which is safer.
5. AC and DC working modes.
6.Observe the window function to observe whether the operation of the infusion set is running in a straight line in real time.
Velocity setting range
Capacity setting range
Fast infusion speed
After the infusion, the infusion rate was 1ml / h
Bubble detection method
Ultrasonic testing method.
Detection bubble size diameter ≤ 3mm (medium speed operation)
Infusion pump self check function
|Power on self-test and real-time detection of infusion process|
Sound and light alarm for abnormal infusion state
|Blocking, infusion completed, battery under voltage, exhaust bubble, door opening, motor fault alarm.|
Setting parameters of infusion pump data memory
|It can store infusion flow rate, infusion flow rate, blocking alarm level and drop value.|
Blocking level setting
The blocking level is set to two levels: Sp1 and SP2.
Injection real time display function
The injection volume can be displayed in real time.
Exhaust bubble function
Before infusion, when there are bubbles in the injection pipeline, press and hold the exhaust bubble key, and the bubbles in the injection pipeline will be emptied at the flow rate of 999ml / h, and the flow rate display screen will display 999ml / h. After the bubbles are discharged, release the exhaust bubble key, and then press the injection button for infusion.
Night infusion pump door lamp on function
At night, the LED lights up when the door is opened. At this time, the infusion will be stopped automatically.
Alarm content flashing function
When there is an alarm, the corresponding alarm content character will flash.
Turn on the power switch and wait for more than one minute before the "standby indicator light flashes" or when there are bubbles and blocking alarms, press the mute key, and wait for more than one minute, "standby indicator light flashes".
Type of velocity setting
Select "ml / h"
Greater than 65dB (sound level at 1m distance)
Internal power supply
Rechargeable lithium battery DC12V, 2000mAh.
Battery charging time
|Less than 15va|
|Class I BF type the equipment is ipx1 type of anti dripping liquid|
Infusion pump noise
|Less than 55dB (sound level at 1m from the front)|
Using ring condition
Rated working low temperature temperature 5 ºC
Low temperature storage temperature - 40 ºC
Rated working high temperature temperature 40 ºC
High temperature storage temperature 55 ºC
Rated working humidity 40 ºC ≤ 90% ± 2RH
Moisture heat storage 40 ºC 90% ± 2RH
|Frequency cycle range 3-8hz|
Displacement amplitude 7.5mm (peak value)
The number of scanning cycles in each direction is 4
|Electrostatic discharge 15kV for air discharge|
Radiation electromagnetic field strength 400A / M
|Rated voltage 1.5kV, duration 60s ± 5S|
|The duration of DC resistance should be greater than 500m Ω for 60s|
|ABS plastic (flame retardant)|
1. Aluminum alloy peristaltic pump body, more accurate infusion.
2. Color screen color large screen display, observation more clear.
3. Import special chip, program running more stable.
4. Keyboard lock function, anti misoperation is safer.
5. Automatic conversion of flow rate and drop number, convenient setting.
6. Automatic control system, suitable for a variety of infusion sets.
7. Automatic adjustment of infusion precision system.
8. Set up observation window of infusion set to ensure the stability of infusion.
9. High quality after-sales service makes it easier to use Q & A at any time.
Q: Are you trading company or manufacturer?
A: We are original manufacturer. We can do OEM/ODM business. We accept small MOQ orders via our Group Buying Project.
Q: What is Group Buying?
A: Group Buying is a project launched by Shanghai Zhenghao. With information technology, this project is targeting on decrease MOQ, price, quality control and after-sales service.
Q: How is the price and service of Group Buying Project ?
A: Price is usually 15% less. The quality and service will be controlled by both the factories and CENTRALIZED ORDERING PROCESS.
Q: How can I join your Group buying Plan?
A: Although Group Buying provides good price with small MOQ and service, but it usually has a long production time. So you need to make good schedule for you purchase, a good plan will let your business more successful.
