Urban Flood Control and Drainage of Axial Flow/Mixed Flow Pump with Large Capacity

Summarize of Urban Flood Control and Drainage of Axial Flow/Mixed Flow Pump with Large Capacity

Installation of water flow Channel: in terms of recommended sample installation diagram
The form of water exit: flap valve or other ways
Installation ways: Floor fixed type, suspended type, floated type and diagnal installed type;
Max. Capacity: 90000m3/h
Max. Head: 20m

Motor of Urban Flood Control and Drainage of Axial Flow/Mixed Flow Pump with Large Capacity
  1. Submersible motor
  2. Power Level: electrical performance conforms to GB756
  3. Protection level: IP68
  4. Voltage grade: ≤1300kw, voltage, 380v, 660v, 6000v, 10000V
  5. Insulation level: F
  6. Rated frequency: 50Hz/60Hz


Urban Flood Control and Drainage of Axial Flow/Mixed Flow Pump with Large Capacity

Shaft seal of Urban Flood Control and Drainage of Axial Flow/Mixed Flow Pump with Large Capacity
There are two or three stages of mechanical seal. The first stage called carborundum (directly contact with water). The second and third stage called graphite and carborundum.
Leak proof Equipment of Urban Flood Control and Drainage of Axial Flow/Mixed Flow Pump with Large Capacity
Sinoflo Axial/Mixed Flow Pump have been equipped with leak proof sensors. When the oil tank, the inner part of motor or the junction box has been leaked by water, the sensor will signal or made the motor shut down, and retain the malfunction signal.
Over heating protection system of Urban Flood Control and Drainage of Axial Flow/Mixed Flow Pump with Large Capacity
A overheating protection device is fastened on the motor winding. When the temperature exceeds the stated value, the device will signal or made the motor shut down.
Rotation direction:
Seen from the top of the motor, the impeller is rotating clock wisely.

Urban Flood Control and Drainage of Axial Flow/Mixed Flow Pump with Large Capacity



Application of Urban Flood Control and Drainage of Axial Flow/Mixed Flow Pump with Large Capacity
Sinoflo axial/mixed flow pump is widely used in industry and agriculture water lifting, urban water supply, light polluted water discharge and other water transfer project.
Working condition of Urban Flood Control and Drainage of Axial Flow/Mixed Flow Pump with Large Capacity
Clean water with the temperature no more than 50 or some liquids that are similar to water.
Urban Flood Control and Drainage of Axial Flow/Mixed Flow Pump with Large Capacity
Urban Flood Control and Drainage of Axial Flow/Mixed Flow Pump with Large Capacity

Urban Flood Control and Drainage of Axial Flow/Mixed Flow Pump with Large Capacity
